Lorentz ps200 hr-07-3 submersible pump system
$ 99.98
Included in price
Carrying Bag
Lorentz ps200 hr-07-3 submersible pump system Lorentz ps200 hr-07-3 submersible pump system DC powered helical rotor has been designed specifically to pump water efficiently using solar power Lorentz ps200 hr-07-3 submersible pump system performance Flow rate: 6,000 litres per day @ 40 meters panels required 2 x 300 watt solar panel Flow rate: 6,000 litres per day @ 25 meters panels required 1 x 330 watt solar panel DC Controller: Lorentz PS2-200 DC controller DC motor: Lorentz ECODRIVE 150-HR-S 0.3 kW IP68 3300 rpm 95mm diameter water filled motor Pump End: HR-07 helical rotor 304/316 ss with rubber stator Pump connection: 32mm FI BSP Pump System PS 200HR-07-3 max. total dynamic head [m] 40 max. flow rate [m³/h] 1.3 Solar Operation: Max Power Voltage (Vmp) >34 Solar Operation: Open Circuit Voltage [V DC] max.100 Solar Operation: Nominal Voltage [V DC] 24-48 Battery Operation: Nominal Voltage [V DC] 24 and 48 Download datasheet
